| ชื่อแบรนด์: | Womeng |
| เลขรุ่น: | WM-SCK01 |
| MOQ: | 1 ชิ้น |
| ราคา: | $500,000.00-$800,000.00 |
| รายละเอียดการบรรจุ: | กล่องไม้ |
| เงื่อนไขการจ่ายเงิน: | l/c, d/a, d/p, t/t |
Product Info
|
Product size
|
M: 680X450 L: 800X650 XL: 950X760(Customixed according to customer requirement)
|
|
Product structure
|
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
|
Control system
|
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
|
|
Drive system
|
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
|
|
Tension system
|
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor. |
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
|
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
|
Materials corrective system
|
Materials corrective system: Adopt international famous brand deviation correction system |
|
Power
|
380V, 50HZ three phase five wire
|
|
Machine Capacity
|
400KW (Excluding glue machine and air compressor)
|
|
Bleed pressure
|
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
|
Whatsapp: +008615805080212
https://www.diapersmachines.com
Adapt to diverse markets: It can meet the needs of different groups of people and scenarios
Multi-category quick switching: Supports full-category switching from "lightweight daily-use style", "thickened night-use style" to "leak-proof care style" and "adult pull-up pants". It only takes 40-80 minutes to change molds or adjust parameters (depending on the actual time), without the need for large-scale equipment modification. Customers can flexibly respond to the consumption preferences of the local market.
Adapt to different body types and demands: It can produce full-size products ranging from "M size (medium body type)" to "XXL size (obese body type)", and can also adjust the "leak-proof edge height" and "absorbent core thickness" according to regional needs (for example, adding thin breathability for tropical countries and enhancing warmth insulation for high-latitude regions), to meet the usage scenarios of local users.
Compatible with local raw materials: It can be adapted to non-woven fabrics, water-absorbing resins, elastic waist belts and other raw materials purchased locally by customers, without relying on specific imported materials. This not only reduces the transportation cost of raw materials but also avoids the impact on production due to supply chain disruptions (such as tariffs and logistics delays), making it particularly suitable for emerging markets with limited raw material procurement channels.
